MSI B550M PRO Motherboard

9,989.00

Out of stock

Get a notification when the item is back in stock.

MSI B550M PRO:-

  • AMD B550
  • Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
  • Supports DDR4 4600+/ 4400/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC MODE
  • Supports DDR4 3200/ 3066/ 3000/ 2933/ 2800/ 2667/ 2400/ 2133/ 1866 MHz by JEDEC
  • 1DPC 1R max speed 4600 MHz
  • 1DPC 2R max speed 3866 MHz
Compare
SKU: B550M PRO Categories: , Tags: , ,

MSI B550M PRO Motherboard


Brand MSI
Series PRO
Model MSI B550M PRO

CPU Socket Type  AM4
CPU Type Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
Chipset  AMD B550

Number of Memory Slots 2×288pin
Memory Standard Supports DDR4 4600+/ 4400/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz by A-XMP OC MODE
Supports DDR4 3200/ 3066/ 3000/ 2933/ 2800/ 2667/ 2400/ 2133/ 1866 MHz by JEDEC1DPC 1R max speed 4600 MHz
1DPC 2R max speed 3866 MHz
Maximum Memory Supported 64GB
Channel Supported  Dual-Channel

PCI Express 4.0 x16 1 x PCIe x16 slot (PCI_E2):
B550M PRO supports PCIe 4.0/3.0
* The supported specification depends on the installed processor.
PCI Express x1 2 x PCIe 3.0 x1 slots

SATA 6Gb/s  4 x SATA 6Gb/s
M.2 1 x M.2 slot (Key M) (from AMD Processor):
B550M PRO Supports PCIe 4.0/3.0 x4 *
Supports SATA 6Gb/s
Supports 2242/2260/2280 storage devices* The supported specification depends on the installed processor.
SATA RAID 0/1/10

Onboard Video Chipset  Supported only by CPU with integrated graphic:
1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz2
1 x HDMI2.1, supports a maximum resolution of 4096×2160@60Hz 12
1 x DisplayPort, supports a maximum resolution of 4096×2160 @60Hz2
Maximum shared memory of 16GB1. Graphics specifications may vary depending on the CPU installed.
2. Available for the processor with integrated graphics.

Audio Chipset  Realtek ALC892/ALC897 Codec
Audio Channels  7.1 Channels

LAN Chipset Realtek RTL8111H
Max LAN Speed 10/100/1000Mbps
Rear Panel Ports
Back I/O Ports 1 x DisplayPort / 1 x D-Sub / 1 x HDMI / 1 x LAN (RJ45) / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 3 x Audio Jacks / 4 x USB 3.2 Gen 1
Onboard USB 1 x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
Other Connectors 1 x Serial port connector
1 x 4-pin CPU fan connector
1 x 4-pin system fan connector
1 x Front panel audio connector
2 x System panel connectors
1 x Chassis Intrusion connector
1 x 4-pin RGB LED connector
1 x 3-pin RAINBOW LED connector
1 x TPM module connector
1 x Clear CMOS jumper
Form Factor Micro ATX
LED Lighting RGB
Dimensions (W x L) 9.6″ x 8.3″
Power Pin 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector

Features Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors

Supports DDR4 Memory, up to 4600(OC) MHz

Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr

M.2 Shield Frozr: Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster

Core Boost: With premium layout and digital power design to support more cores and provide better performance

DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability

2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability

Audio Boost: Reward your ears with studio grade sound quality

Dragon Center: A brand new software that integrates all MSI exclusive tools with the user-friendly user interface



Related Product: https://www.pcisland.in/product-category/pc-parts/motherboard/

Read More About MSI B550M PRO: https://www.msi.com/index.php

Additional information

Weight 0.01 kg
Dimensions 24 × 22 × 3 cm
Platform

Manufacturer

Chipset

Form Factor

Max Memory Support

Memory Type

Multi GPU Support

Socket

TDP
