Intel Pentium Gold G5420 Processor (4M Cache, 3.80 GHz)
Roll over image to zoom in
₹5,999.00₹9,000.00 (-33%)
Intel Pentium Gold G5420
- Intel Pentium Gold G5420 Processor (4M Cache, 3.80 GHz)
- Intel Pentium Gold Processor SeriesProducts formerly Coffee LakeDesktopG542014 nm3.80 GHz4 MB Intel Smart Cache8 GT/s54 WIntel UHD Graphics 610350 MHz and 4k Graphics, at 60Hz
- BX80684G5420
- PG5420
Intel Pentium Gold G5420
Intel Pentium Gold G5420 Specifications:
Essentials |
|
| Vertical Segment | Desktop |
| Processor Number | G5420 |
| Lithography | 14 nm |
| Performance | |
| Cores | 2 |
| Threads | 4 |
| Processor Base Frequency | 3.80 GHz |
| Cache | 4 MB Intel® Smart Cache |
| TDP | 54 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 64 GB |
| Memory Types | DDR4-2400 |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 37.5 GB/s |
| ECC Memory Supported | Yes |
| Graphics Specifications | |
| Processor Graphics | Intel® UHD Graphics 610 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.05 GHz |
| Graphics Video Max Memory | 64 GB |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | 4096×2304@24Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.5 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| Displays Supported | 3 |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 3.0 |
| PCI Express Configurations | Up to 1×16, 2×8, 1×8+2×4 |
| Max # of PCI Express Lanes | 16 |
| Package Specifications | |
| Sockets Supported | FCLGA1151 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2015C (65W) |
| TJUNCTION | 100°C |
| Advanced Technologies | |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® vPro™ Platform Eligibility | No |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel® Stable Image Platform Program (SIPP) | No |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® ME |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | No |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
Related Products: https://www.pcisland.in/product-category/pc-parts/
Additional information
| Weight | .450 kg |
|---|---|
| Dimensions | 11.6 × 7 × 10.1 cm |
| Manufacturer | |
| Threads | |
| Base Clock | |
| TDP |
